FRONT OF HOUSE

Console:
Midas Heritage HD 96 44 mono, 4 stereo inputs

Outboard Gear:
(1) Marantz PMD 330 CD Player

Clear Com:
(1) Master Controller (single chan) with (10) Remote Belt Packs/Headsets

House Crossover:
(2) XTA DP448 (4×8)

House Power:
(7) Lab Gruppen C48

(4) Lab Gruppen C28

House Speakers:
(6) Electro Voice – MTH 4
(6) Electro Voice – MTL 4

Center and Balcony Fills:
Bi-amped, stereo, front fills hung above side fills at stage left and right, balcony fills hung on house left and right walls at end of each balcony, controlled via 1 matrix out at FOH. Separate control available upon request via crossover.
(4) EAW JF10
(1) Ashly 2-channel EQ

House Snake:
Whirlwind 56 x 8 Concert Series Trans. 2 way Split (Pin 2 HOT]) + (3) Stage Boxes 16-20 chan. (4 w/ returns). 1 separate CAT5/RJ45 line from FOH to stage.

STAGE MONITOR SYSTEM

Console:

(1) Avid Venue Profile
–16 Balanced outputs & 8 Unbalanced
(1) Mix Rack & VenuePack 3 Plugins
–2 8 channel output cards
–1 8 channel output TRS
Please note, NO AES, HDX or Firewire cards.
Standard 2 DSP cards are installed.

EQ:
(1) KlarkTechnik DN 360b (30 band, 2 channel)

Power:
(3) Lab Gruppen C48:4 Power Amplifiers
(2) Lab Gruppen C16:4 Power Amplifiers
(1) Lab Gruppen C28:4 Power Amplifier

Processing:
(3) XTA DP448 DSP Crossovers (4in x 8out)

Speakers
(11) Adamson M12 Monitor Wedges
(1) Adamson Sx18 Drum Fill
(2) Adamson Sx18 Side Fills
More mixes and drives are available with adequate notice.
Normal setup is eight bi-amped wedge mixes, two side fill mixes and one drum fill. Capable of Twelve bi-amped wedge mixes total. More mixes are available with adequate notice

HOUSE LIGHTING SYSTEM

Moving Lights:
7x Elation Platinum Spot Pro 15Rs
4x High End Studio Color 250s

Conventional:
20 S4 Leko’s 575Watt (8 DS Catwalk, 12 Balcony)
4 S4 Pars 575Watt (blinders)

LED Fixtures:
14 Elation Arena Pars (12 over stage, 2 for dome)

Console:
Avolites Pearl Expert Pro with Touch Wing and accessible via closed wifi network

Dimmers:
7x Elation DP-640B 6 channel packs

Follow Spots:
2x Satellite 575 Watt HMI Follow Spotlights

Effects:
Master FX Mystic Mini

VIDEO CAPABILITIES

Display:
2x Panasonic PT-DZ6700 1920 x 1200 Pixel HD Projectors
2x 10′ x 16′ Retractable Screens House Left & Right
8x 49” LG Commercial Monitors in House Left and Right
2x 43” LG Commercial Monitors Under House Stairs
2x 49” LG Commercial Monitors Under House Stairs
4x 43” LG Commercial Monitors in Lobby
1x 15” Preview Monitor on Stage Right
1x 20” Preview Monitor in Video Booth
4x 7” Preview Monitors in Video Booth

Playback:
2x Windows 10 Computers for Client PowerPoints etc.
1x Denon Commercial Blu-Ray Player

Routing/Patching:
HDMI / IP Based Routing System
AMX NX-3200 Network Controller
Luxul 48 Port POE Switch
Windows 10 PC with Beetronics 19” Touchscreen Interface for Routing Control
HDMI Inputs and Outputs Throughout Venue

Power:
2 x 200 amp 120/240 Single Phase
2 x 100 amp 120/240 Single Phase (shore power)
2 x 50 amp 120/240 Single Phase

Staging:
8x 4’x8’ Decks
2x 4’x6’ Decks
Legs: 8”, 16”, 26”, 32”

Dressing Rooms:
We have two dressing rooms in house, one star dressing room – 14’x17’ with restroom and one shower. The dressing room is located in the back corner, 2nd floor of the house. The secondary/support dressing room is a private kitchen area that converts into dressing room space – 19’x12’ with a restroom. There is access to stage via hallway around the house left perimeter of house.

WIFI:
Guest network

Parking:
We are in a residential neighborhood and parking is very tight. We can accommodate about ten cars or two busses with trailers, with more available upon request.

Shore Power:
2x 50amp shore powers available on standard 14-50 appliance plugs.

Merch:
We have a small area for merch sales in our lobby, approximately 6’x6’ with three tables.

Talent Guest Area:
Located in the House Left balcony near the tech area and main dressing room. Space is 12’x 6.5’ and can seat approximately 15 people sitting or 25 standing. Other accommodations can be made upon request.

Microphones:
3 Shure Beta 52
6 Shure Beta 58A
2 Shure SM 91
4 Shure SM 98
6 Shure SM 58
4 Shure SM 86
2 Shure KSM 44
2 Shure KSM 137
2 Shure KSM 32
1 Shure VP 88
4 Shure Beta 56
2 Shure KSM 141
8 Shure Beta 87C
2 Shure Beta 87A
6 Shure SM 81
10 Shure SM 57
2 Shure KSM 9
4 Shure 89
2 Shure WL50 Cardioid
1 Shure WL41 Omni
6 Shure WL183 Lavalier
2 Shure MX153 Headset
2 Shure WL183 Omni
6 Shure U4D 2 ChannelUHF
2x Switched 58’s for FOH and Mons positions.
3x Beta181′
4x Beta98AMP
6x MX184′
1x Beta91A
3x SM58;s
2x KSM32′
2x Beta57s

Direct Boxes:
2 Missing Link ADI
1 Helpinstill 3-way piano pickup
4 Whirlwind Director PDI
2 DB1 PDI
1 BSS AR-133 ADI
2 Missing Link PDI
6 Countryman 85 FET ADI
1 Whirlwind 4 Channel Director
1 Klark Teknik ADI

Stands:
19 Tall Straights with 16 Booms
9 LP Claws
2 Heavy Duty Atlas Triangle Base Booms
4 Shure SM 98 Clamps
5 Short Booms
7 Goose necks & piano clamps
8 Tall tripod with Booms
10 Music stands w/lights
